This notebook reproduces the results from Wu et al.. In [1], the authors propose a circularly polarized antenna with parasitic strips that has a lower profile and an improved circularly polarized bandwidth when compared to existing designs. This notebook also serves to introduce many key components of Tidy3D that are used in antenna simulations:
- DirectivityMonitor: The directivity monitor records and stores electromagnetic field data, which it uses to calculate far-field quantities such as radiation intensity and directivity.
- CoaxialLumpedPort: These ports are used to model a coaxial-type excitation, which includes a current source and load impedance.
-
TerminalComponentModeler: This tool, in the
smatrixplugin, enables the calculation of scattering parameters and also the incident and reflected powers at each port, which is needed for calculating the antenna gain. TheTerminalComponentModelermay be used to calculate many parameters of interest in antenna design. These antenna parameters are returned as a AntennaMetricsData, which is calculated in a post-processing step after all simulations are completed. - LobeMeasurer: This helper class finds the lobes in a radiation pattern and calculates lobe measures, such as the half power beamwidth.
Since this notebook uses many features, you may find the following notebooks helpful for understanding each feature separately.
# standard python imports
import numpy as np
import matplotlib.pyplot as plt
# tidy3d imports
import tidy3d as td
# Import a few plugins which contain some of the tools we will use in this tutorial
import tidy3d.plugins.smatrix as smatrix
from tidy3d.plugins.dispersion import (
FastDispersionFitter
)
from tidy3d.plugins.microwave import (
LobeMeasurer
)
td.config.logging_level = "ERROR"
Simulation Parameter Setup¶
We begin by setting the frequency range of interest (2.2 GHz to 3 GHz), which will be used to set up the source and monitors in the simulation. Next, we define geometric parameters from [1] that describe the shape and placement of the various components used in the antenna design. To compute $S_{11}$ of the antenna, we will use the TerminalComponentModeler, which requires setting up a port excitation. The antenna in [1] is backed by a ground plane and excited by a feeding pin. In order to emulate a 50 $\Omega$ coaxial cable connected to the feeding pin, we introduce a 1.5 mm radius hole in the ground plane where we will place a CoaxialLumpedPort.
We model all conductors from [1] as perfect electric conductors (PECs). In [1], the substrate is modeled with a relative permittivity of 2.55 and frequency-independent loss tangent of 0.002. To ensure causality, in Tidy3D the loss tangent must be modeled using a dispersive material with pole-residue pairs. Fortunately, we can use the constant_loss_tangent_model to easily generate such a model.
# Frequency range of interest is 2.2 to 3 GHz
freq_start = 2.2e9
freq_stop = 3e9
# Center frequency of 2.6 GHz
freq0 = (freq_start + freq_stop) / 2
fwidth = freq_stop - freq_start
# Frequency sample points for monitors and post-processing
freqs = np.linspace(freq_start, freq_stop, 51)
# Center wavelength
wavelength0 = td.C_0 / freq0
# Longest wavelength
wavelength_start = td.C_0 / freq_start
# Run time of FDTD simulation
run_time = 10 / fwidth
# Tidy3D uses microns by default
mm = 1e3
# Parameters from [1]
G = 130 * mm # Length and width of ground sheet
L = 73 * mm # Length and width of substrate
L1 = 39 * mm # Length and width of center patch
a = 21 * mm # Width of corner cutout of center patch
fx = 15 * mm # X position of feed pin
gx = 2 * mm # Horizontal gap distance between center patch and parasitic patches
gy = 8 * mm # Vertical gap distance between substrate boundary and parasitic patches
Ls = 36 * mm # Length of parasitic patches
Ws = 15 * mm # Width of parasitic patches
r1 = 2 * mm # Ground pin pad size
r2 = 1.7 * mm # Feed pin pad size
t = 1 * mm # Substrate thickness
H = 14 * mm # Distance between ground and substrate
rfeed = 0.65 * mm
# Custom parameters chosen for this simulation, not specified in [1]
# Chosen thickness of metal conductors other than the ground sheet (20 microns)
patch_thickness = 0.02 * mm
ground_thickness = 0.16 * mm
# Using an outer radius of 1.5 mm gives about 50 Ohms
# for the impedance of air filled coax that connects to the feeding pin.
coax_radius = 1.5 * mm
# Total structure height
structure_height = t + H + ground_thickness + patch_thickness
structure_center = 0.5 * (t + patch_thickness - H - ground_thickness)
# Define key vertical locations within the simulation domain.
top_substrate = t
bottom_substrate = 0
middle_ground = -H - ground_thickness / 2
port_location = -H - ground_thickness # Port is located at the bottom of the ground.
# Calculate the diameter of the coaxial port based on the radius.
port_diameter = 2 * coax_radius
# PML buffer size added around structures
PML_buffer = wavelength_start / 2
# Simulation domain definition with sufficient padding around the structure for PMLs
sim_size = (G + 2 * PML_buffer, G + 2 * PML_buffer, structure_height + 2 * PML_buffer)
sim_center = [0, 0, structure_center]
# Define media in the simulation
epsr_sub = 2.55
air = td.Medium()
metal = td.PECMedium()
# Use FastDispersionFitter to create a material with an approximately correct loss tangent for the frequency range.
substrate_med = FastDispersionFitter.constant_loss_tangent_model(
epsr_sub, 0.002, (freq_start, freq_stop)
)
Output()
Create Structures¶
Next, we use the defined parameters to create all of the structures in the Tidy3D simulation and plot the created structure.
def make_structures(differential_feed: bool = False):
"""Makes all of the Tidy3D structures that represent the antenna in [1]. As in [1], we can choose to model the antenna
with a differential feed, where a second feeding pin is added to the structure.
"""
# Make structures for the simulation for either the proposed or differential feeds in [1].
# Dielectric substrate that extends from the shorting and feeding pins to the patches
substrate = td.Structure(
geometry=td.Box(
center=[0, 0, t / 2],
size=[L, L, t],
),
medium=substrate_med,
)
# A ground plane is connected to the bottom of the pins, where a small air gap is introduced for exciting the
# feeding pin
ground_box = td.Box(
center=[0, 0, -H - ground_thickness / 2], size=[G, G, ground_thickness]
)
# A cylindrical hole is created in the ground plane to allow for the coaxial cable connection at the feeding pin.
feed_gap = td.Cylinder(
center=(fx, 0, -H - ground_thickness / 2),
radius=coax_radius,
length=ground_thickness,
axis=2,
)
if differential_feed:
left_feed_gap = td.Cylinder(
center=(-fx, 0, -H - ground_thickness / 2),
radius=coax_radius,
length=ground_thickness,
axis=2,
)
feed_gap = td.GeometryGroup(geometries=(feed_gap, left_feed_gap))
# The air gap is removed from the ground box
ground_with_holes = td.ClipOperation(
operation="difference", geometry_a=ground_box, geometry_b=feed_gap
)
# The final ground plane structure is created
ground = td.Structure(
geometry=ground_with_holes,
medium=metal,
)
# Define the vertices that outline the shape of the central patch.
main_vertices = np.array(
[
(-L1 / 2, -L1 / 2),
(L1 / 2 - a, -L1 / 2),
(L1 / 2, -L1 / 2 + a),
(L1 / 2, L1 / 2),
(-L1 / 2 + a, L1 / 2),
(-L1 / 2, L1 / 2 - a),
]
)
# Using the vertices, a polyslab structure is created with the previously defined patch_thickness.
main_patch = td.Structure(
geometry=td.PolySlab(
vertices=main_vertices.tolist(),
slab_bounds=(t, t + patch_thickness),
axis=2,
),
medium=metal,
)
# The remaining parasitic strips are sequentially-rotated rectangles around the central patch.
patch_L = td.Box(
center=(-L / 2 + Ws / 2, -L / 2 + gy + Ls / 2, t + patch_thickness / 2),
size=(Ws, Ls, patch_thickness),
)
patch_R = td.Box(
center=(L / 2 - Ws / 2, L / 2 - gy - Ls / 2, t + patch_thickness / 2),
size=(Ws, Ls, patch_thickness),
)
patch_B = td.Box(
center=(L / 2 - Ls / 2 - gy, -L / 2 + Ws / 2, t + patch_thickness / 2),
size=(Ls, Ws, patch_thickness),
)
patch_T = td.Box(
center=(-L / 2 + Ls / 2 + gy, L / 2 - Ws / 2, t + patch_thickness / 2),
size=(Ls, Ws, patch_thickness),
)
# Conductive pads for the feeding and shorting pins, placed at the bottom of the substrate.
feed_disc = td.Cylinder(
center=(fx, 0, -patch_thickness / 2), radius=r2, length=patch_thickness, axis=2
)
if differential_feed:
shorted_disc = td.Cylinder(
center=(-fx, 0, -patch_thickness / 2), radius=r2, length=patch_thickness, axis=2
)
else:
shorted_disc = td.Cylinder(
center=(0, 0, -patch_thickness / 2), radius=r1, length=patch_thickness, axis=2
)
# All patch structures are collected into a list and assigned the same material
patch_geoms = [patch_L, patch_R, patch_B, patch_T, feed_disc, shorted_disc]
patch_structures = [
td.Structure(geometry=patch, medium=metal) for patch in patch_geoms
]
# Next, the shorting and feeding pins are added to the simulation as cylinders.
if differential_feed:
# Short pin represents the other feed when using the differential feed configuration.
short_pin = td.Structure(
geometry=td.Cylinder(
center=(-fx, 0, -H / 2 - ground_thickness / 2),
radius=rfeed,
length=H + ground_thickness,
axis=2,
),
medium=metal,
)
else:
short_pin = td.Structure(
geometry=td.Cylinder(
center=(0, 0, -H / 2 - ground_thickness / 2),
radius=rfeed,
length=H + ground_thickness,
axis=2,
),
medium=metal,
)
feed_pin = td.Structure(
geometry=td.Cylinder(
center=(fx, 0, -H / 2 - ground_thickness / 2),
radius=rfeed,
length=H + ground_thickness,
axis=2,
),
medium=metal,
)
# Create a list of all structures in the simulation.
return [
substrate,
ground,
feed_pin,
short_pin,
main_patch,
] + patch_structures
structures_list = make_structures(differential_feed=False)
# Setting up the scene for visualization, with all structures included
# and units set to millimeters for the plot.
scene = td.Scene(structures=structures_list, plot_length_units="mm")
fig, axs = plt.subplots(1, 2, figsize=(10, 5), tight_layout=True)
sub_ax = axs[0]
scene.plot(z=t, ax=sub_ax)
sub_ax.set_xlim(-L / 2, L / 2)
sub_ax.set_ylim(-L / 2, L / 2)
sub_ax = axs[1]
scene.plot(y=0, ax=sub_ax)
sub_ax.set_xlim(-L / 3, L / 3)
sub_ax.set_ylim(-H - t, 2 * t)
plt.show()
Mesh Overrides and Layer Refinement Specification¶
In this antenna design, there are many subwavelength features that may not be captured accurately using the default grid generated by Tidy3D, even when using the PECConformal subpixel feature. For instance, both the metal patch thickness and the gap between the central patch and parasitic strips are subwavelength. In addition, the radius of the shorting pin and feeding pin are also relatively small. To enhance the accuracy of this simulation, we will use two components: MeshOverrideStructures and LayerRefinementSpec.
The MeshOverrideStructures are used to refine the grid near the locations of the shorting and feeding pins. We use MeshOverrideStructures to ensure that there will be about four grid cells in the gap between the feeding pin and ground plane, where the excitation will be placed. Finally, another similar MeshOverrideStructure is added near the shorting pin to resolve the cylinder's surface accurately.
We also make use of the LayerRefinementSpec feature, which automatically creates refined mesh in each layer defined by the user. We choose to refine the mesh around metallic objects on the top and bottom of the substrate. In addition, we add a LayerRefinementSpec corresponding to the ground plane.
def make_grid_spec(use_differential_feed: bool = False):
# Make a GridSpec for the simulation for either the proposed or differential feeds in [1].
# Set the size of grid cells to be used for the portion of the structure containing all patches.
# Choose the cell size in the xy-plane to ensure there are 4 cells across the gap between the main patch and parasitic strips.
dl_plane = gx / 4
# Vertical cell size around printed components
dz_metal = 100
# Provide a larger cell size (dl value) for regions or dimensions that do not require fine resolution.
dl_background = 10 * mm
# Set the cell size at the port to fit approximately `port_cells` between the feed pin and ground
port_cells = 4
dl_pins = (coax_radius - rfeed) / port_cells
# Add MeshOverrideStructures around both pins, which will capture the curved geometry of the cylinders more accurately.
# These MeshOverrideStructures also improve the accuracy of the fields in the air gap, where the port excitation will be placed.
short_x_center = 0
if use_differential_feed:
short_x_center = -fx
mesh_overrides = [
td.MeshOverrideStructure(
geometry=td.Box(
center=[fx, 0, middle_ground],
size=[port_diameter, port_diameter, ground_thickness],
),
dl=[dl_pins, dl_pins, dl_background],
),
td.MeshOverrideStructure(
geometry=td.Box(
center=[short_x_center, 0, middle_ground],
size=[port_diameter, port_diameter, ground_thickness],
),
dl=[dl_pins, dl_pins, dl_background],
),
]
top_substrate_spec = td.LayerRefinementSpec.from_layer_bounds(
bounds=(top_substrate, top_substrate + patch_thickness),
axis=2,
bounds_snapping="lower",
bounds_refinement=td.GridRefinement(dl=dz_metal),
corner_refinement=td.GridRefinement(dl=dl_plane/2)
)
bottom_substrate_spec = td.LayerRefinementSpec.from_layer_bounds(
bounds=(bottom_substrate - patch_thickness, bottom_substrate),
axis=2,
bounds_snapping="upper",
bounds_refinement=td.GridRefinement(dl=dz_metal)
)
ground_spec = td.LayerRefinementSpec.from_layer_bounds(
min_steps_along_axis=1,
bounds=(-H - ground_thickness, -H),
axis=2,
bounds_snapping="bounds",
)
return td.GridSpec.auto(
min_steps_per_wvl=20,
wavelength=td.C_0 / freq_stop,
layer_refinement_specs=[top_substrate_spec, bottom_substrate_spec, ground_spec],
override_structures=mesh_overrides,
)
grid_spec = make_grid_spec(use_differential_feed=False)
Now, we plot the created geometry along with the FDTD grid to see how the MeshOverrideStructures and LayerRefinementSpecs have affected the grid. In the first figure, you can clearly see the mesh refinement created by the MeshOverrideStructures around the shorting and feeding pins. The figure on the right shows a close-up of the gap region between the central patch and a parasitic strip. The purple markers indicate the locations of corners where the mesh grid has been snapped and refined. The subsequent plot illustrates the refined grid near the port location, clearly showing the desired four grid cells between the inner and outer conductors.
# Create simulation object, so that we can view the created grid superimposed with simulation structures.
sim = td.Simulation(
center=sim_center,
size=sim_size,
grid_spec=grid_spec,
structures=structures_list,
run_time=run_time,
plot_length_units="mm"
)
# Display information about the simulation grid, including the number of cells along each axis and the smallest cell size,
# which are important for simulation accuracy.
print(sim.grid_info)
# Create two plots: one showing the overall grid and simulation setup, and another zoomed in near the gap and feed pin location.
fig, axs = plt.subplots(1, 2, figsize=(10, 10), tight_layout=True)
sub_ax = axs[0]
sim.plot(z=t, ax=sub_ax, monitor_alpha=0)
sim.plot_grid(z=t, ax=sub_ax)
sub_ax.set_xlim(-L / 2, L / 2)
sub_ax.set_ylim(-L / 2, L / 2)
sub_ax = axs[1]
sim.plot(z=t, ax=sub_ax, monitor_alpha=0)
sim.plot_grid(z=t, ax=sub_ax)
sub_ax.set_xlim(L1 / 2 - 4 * gx, L1 / 2 + 4 * gx)
sub_ax.set_ylim(L / 2 - gy - Ls - 2 * gx, L / 2 - gy - Ls + 6 * gx)
plt.show()
# Create a detailed plot at the port location to verify the mesh refinement in this critical region.
fig, ax = plt.subplots(figsize=(5, 5), tight_layout=True)
sim.plot(z=port_location, ax=ax)
sim.plot_grid(z=port_location, ax=ax)
ax.set_xlim(fx - 5 * mm, fx + 5 * mm)
ax.set_ylim(-5 * mm, 5 * mm)
plt.show()
{'Nx': 274, 'Ny': 255, 'Nz': 103, 'grid_points': 7196610, 'min_grid_size': 75.0, 'max_grid_size': 4996.540966666886, 'computational_complexity': 95954.8}
Simulation Monitors¶
In this notebook, we wish to compute a variety of antenna parameters. We will first create plots of the normalized radiation pattern at 2.6 GHz for right-handed and left-handed circular polarizations. We will also reproduce a few plots from [1] that are functions of frequency, i.e., the axial ratio and the antenna gain along the z axis. In order to create these plots efficiently, we use one DirectivityMonitor that records the far-field pattern over a range of directions at a fixed frequency. We use a separate DirectivityMonitor to capture the field over a range of frequencies at a specific observation point, denoted by spherical coordinates $(\theta=0, \phi=0)$.
# Place the far field monitors just inside simulation boundaries
farfield_size = (sim_size[0] * 0.9, sim_size[1] * 0.9, sim_size[2] * 0.9)
# Radial distance away from the origin at which to project fields.
r_proj = 50 * wavelength0
# Theta and Phi angles at which to observe fields
theta_proj = np.linspace(0, 2 * np.pi, 200, endpoint=False)
phi_proj = np.linspace(0, np.pi / 2, 2)
# First, create a FieldProjectionAngleMonitor that will be used to plot the radiation pattern in the xz and yz planes
mon_rad_spatial = td.DirectivityMonitor(
center=sim_center,
size=farfield_size,
# the size and center of any far field monitor should indicate where the *near* fields are recorded
freqs=[freq0],
name="rad_spatial",
phi=list(phi_proj),
theta=list(theta_proj),
proj_distance=r_proj,
far_field_approx=True, # Compute the radiated fields in the far field.
)
# Next, create a FieldProjectionAngleMonitor that will be used to compute radiated fields normal to the antenna vs the frequency.
mon_rad_freqency = td.DirectivityMonitor(
center=sim_center,
size=farfield_size,
freqs=freqs, # Record radiated fields for different frequencies.
name="rad_frequency",
phi=[0], # Record radiated fields normal to the antenna
theta=[0],
proj_distance=r_proj,
far_field_approx=True, # Compute the radiated fields in the far field.
)
Set up the TerminalComponentModeler¶
The last step before launching the simulation is to set up the TerminalComponentModeler, which will simplify the calculation of $S_{11}$. As previously mentioned, we use a CoaxialLumpedPort with a reference impedance of $50 \Omega$ as the source. The CoaxialLumpedPort will model a radially directed uniform current source and an annular resistive load between the feed pin and ground plane. Scattering parameters calculated with this definition of the CoaxialLumpedPort should match experimental results where a coaxial cable is used with characteristic impedance of $50 \Omega$.
# Use a CoaxialLumpedPort to excite the feed pin. The CoaxialLumpedPort models a radially symmetric current
# flowing from the feed pin to the ground plane through a resistive element.
coax_center = [fx, 0, port_location]
coax_port = smatrix.CoaxialLumpedPort(
center=coax_center,
outer_diameter=port_diameter,
# Defines the boundary for the outer conductor, which in this case is the ground plane.
inner_diameter=2 * rfeed, # Defines the boundary for the inner conductor, corresponding to the feed pin diameter.
normal_axis=2,
direction="+", # Indicates that the current will flow in the positive direction along the feed pin.
name="coax_port",
num_grid_cells=None, # The port grid refinement is handled manually with MeshOverrideStructures, hence 'None'.
)
modeler = smatrix.TerminalComponentModeler(
simulation=sim,
ports=[coax_port],
radiation_monitors=(mon_rad_spatial, mon_rad_freqency),
freqs=freqs,
remove_dc_component=True,
verbose=True,
)
Next, we run the simulation that computes the scattering matrix. After the simulation is complete, we retrieve the BatchData and SimulationData, which contain the results from the far-field monitors.
# Run the TerminalComponentModeler and populate the scattering matrix of this single CoaxialLumpedPort network.
s_matrix = modeler.run()
Output()
15:55:17 EST Started working on Batch containing 1 tasks.
15:55:18 EST Maximum FlexCredit cost: 0.245 for the whole batch.
Use 'Batch.real_cost()' to get the billed FlexCredit cost after the Batch has completed.
Output()
15:56:17 EST Batch complete.
Output()
Postprocessing¶
Polar plots of normalized radiation patterns¶
We will use the simulation results to reproduce Fig. 10 (b) from [1]. First, we retrieve the radiation intensities using the helper method get_antenna_metrics_data, which returns a AntennaMetricsData object. The radiation intensities are obtained in the circular polarization basis, which is decomposed into right-handed circular polarization (RHCP) and left-handed circular polarization (LHCP) components. Then, we normalize by the peak total radiation intensity.
antenna_parameters_spatial = modeler.get_antenna_metrics_data(monitor_name="rad_spatial")
partial_U = antenna_parameters_spatial.partial_radiation_intensity(pol_basis="circular").sel(
f=freq0
)
peakU = np.max(antenna_parameters_spatial.radiation_intensity)
normalized_partial_U = partial_U / peakU
# Select fields along theta for phi = 0 and phi = pi/2
Urad_RH_Phi_0 = normalized_partial_U.Uright.sel(phi=0).squeeze().values
Urad_LH_Phi_0 = normalized_partial_U.Uleft.sel(phi=0).squeeze().values
Urad_RH_Phi_90 = normalized_partial_U.Uright.sel(phi=np.pi / 2).squeeze().values
Urad_LH_Phi_90 = normalized_partial_U.Uleft.sel(phi=np.pi / 2).squeeze().values
# Plot the normalized radiation pattern similar to [1].
fig, ax = plt.subplots(1, 2, subplot_kw={"projection": "polar"}, figsize=(8, 4))
sub_ax = ax[0]
sub_ax.set_theta_direction(-1)
sub_ax.set_theta_offset(np.pi / 2.0)
sub_ax.plot(theta_proj, 10 * np.log10(Urad_RH_Phi_0), "-k", label="RHCP")
sub_ax.plot(theta_proj, 10 * np.log10(Urad_LH_Phi_0), "-r", label="LHCP")
sub_ax.set_rlim(-40, 0)
sub_ax.set_rticks([-40, -30, -20, -10, 0])
sub_ax.set_title(r"Radiation Pattern ($\phi = 0$)")
sub_ax.legend(loc="lower center", ncols=2)
sub_ax = ax[1]
sub_ax.set_theta_direction(-1)
sub_ax.set_theta_offset(np.pi / 2.0)
sub_ax.plot(theta_proj, 10 * np.log10(Urad_RH_Phi_90), "-k", label="RHCP")
sub_ax.plot(theta_proj, 10 * np.log10(Urad_LH_Phi_90), "-r", label="LHCP")
sub_ax.set_rlim(-40, 0)
sub_ax.set_rticks([-40, -30, -20, -10, 0])
sub_ax.set_title(r"Radiation Pattern ($\phi = \pi/2$)")
sub_ax.legend(loc="lower center", ncols=2)
fig.tight_layout()
plt.show()
Finding antenna lobes with the LobeMeasurer¶
Given a 1D array of values representing the radiation pattern, we can use the LobeMeasurer tool to find the direction of the main antenna lobes.
xz_plane_lobe_measurer = LobeMeasurer(angle=theta_proj, radiation_pattern=Urad_RH_Phi_0)
main_lobe_phi_0 = xz_plane_lobe_measurer.main_lobe["direction"]*180/np.pi
yz_plane_lobe_measurer = LobeMeasurer(angle=theta_proj, radiation_pattern=Urad_RH_Phi_90)
main_lobe_phi_90 = yz_plane_lobe_measurer.main_lobe["direction"]*180/np.pi -360
print(f"The main lobe direction in the xz-plane is {main_lobe_phi_0:.2f} degrees.")
print(f"The main lobe direction in the yz-plane is {main_lobe_phi_90:.2f} degrees.")
The main lobe direction in the xz-plane is 5.40 degrees. The main lobe direction in the yz-plane is -10.80 degrees.
The beam directions are close to the values reported in [1], which are 5 degrees in the xz plane and -10 degrees in the yz plane.
Plot of $S_{11}$¶
Next, we reproduce Fig. 9 (a) from [1] using the scattering parameter computed by the TerminalComponentModeler.
# Plot the reflection coefficient using the scattering parameter computed by the TerminalComponentModeler
freq = s_matrix.f / 1e9
s_11 = 20 * np.log10(np.abs(s_matrix.isel(port_out=0, port_in=0).values.flatten()))
plt.plot(freq, s_11, "-b")
plt.xlabel("Frequency (GHz)")
plt.ylabel(r"$|S_{11}|$ (dB)")
plt.title(r"Plot of $S_{11}$")
# Make the plot identical to [1].
plt.xlim(2.1, 3.1)
plt.ylim(-40, 0)
plt.yticks([-40, -30, -20, -10, 0])
plt.grid(True)
plt.show()
Compute and plot the axial ratio¶
Next, we use the simulation results to reproduce Fig. 9 (a) from [1].
# Retrieve the field data from the "rad_frequency" monitor
antenna_parameters_freq = modeler.get_antenna_metrics_data(monitor_name="rad_frequency")
axial_ratio = antenna_parameters_freq.axial_ratio
freq = axial_ratio.f.values.squeeze() / 1e9
axial_ratio_dB = 20 * np.log10(np.abs(axial_ratio.values.squeeze()))
plt.plot(freq, axial_ratio_dB, '-b')
plt.xlabel('Frequency (GHz)')
plt.ylabel('Axial ratio (dB)')
plt.title('Axial ratio')
# Make the plot identical to [1].
plt.xlim(2.1, 3.1)
plt.ylim(0, 12)
plt.yticks([0, 3, 6, 9, 12])
plt.grid(True)
plt.show()
Compute and plot the antenna gain for RHCP¶
We plot the antenna gain for the RHCP component. These results can be retrieved from AntennaMetricsData by specifying a "circular" polarization basis.
The gain is calculated by multiplying the directivity by the radiation efficiency of the antenna. The resulting plot will replicate Fig. 9 (b) from [1].
freq = antenna_parameters_freq.f.squeeze() / 1e9
gain = antenna_parameters_freq.partial_gain(pol_basis="circular").Gright.values.squeeze()
gain_dB = 10 * np.log10(gain)
plt.plot(freq, gain_dB, '-b')
plt.xlabel('Frequency (GHz)')
plt.ylabel('Gain (dB)')
plt.title('Gain')
plt.xlim(2.1, 3.1)
plt.ylim(5, 10)
plt.yticks([6, 7, 8, 9])
plt.grid(True)
plt.show()
Setting Up and Simulating the Differential Feed Antenna Configuration¶
In [1], the proposed single-feed excitation is compared to a differential feed excitation, where the ground pin is removed and a second feed pin is added. We can reproduce the results in [1] by changing the Tidy3D simulation to reflect the new geometry, as well as adding an additional coaxial port to the TerminalComponentModeler.
The radiated fields due to the differential feed configuration can be calculated as a post-processsing step in the TerminalComponentModeler, which forms a superposition of the fields with user-defined port amplitudes. However, unlike the single feed case, we need to recompute the radiated power by integrating over a spherical surface. As a result, we need to ensure that the DirectivityMonitor samples the electromagnetic field over an entire sphere. In this section, we will use a single DirectivityMonitor that will sample both the spatial coordinates and all desired frequency values.
#Create simulation in the differential feed configuration
structures_list = make_structures(True)
grid_spec = make_grid_spec(True)
#Create a new monitor that samples entire spherical surface
theta_proj2 = np.linspace(0, np.pi, 101)
phi_proj2 = np.linspace(0, 2*np.pi, 200)
# First, create a DirectivityMonitor that will be used to plot the radiation pattern in the xz and yz planes
mon_rad_spatial = td.DirectivityMonitor(
center=sim_center,
size=farfield_size,
freqs=freqs,
name="rad_spatial",
phi=list(phi_proj2),
theta=list(theta_proj2),
proj_distance=r_proj,
far_field_approx=True, # Compute the radiated fields in the far field.
)
sim = sim.updated_copy(structures=structures_list, grid_spec=grid_spec)
# Setting up the scene for visualization, with all structures included
# and units set to millimeters for the plot.
scene = td.Scene(structures=structures_list, plot_length_units="mm")
fig, axs = plt.subplots(1, 2, figsize=(10, 5), tight_layout=True)
sub_ax = axs[0]
scene.plot(z=t, ax=sub_ax)
sub_ax.set_xlim(-L / 2, L / 2)
sub_ax.set_ylim(-L / 2, L / 2)
sub_ax = axs[1]
scene.plot(y=0, ax=sub_ax)
sub_ax.set_xlim(-L / 3, L / 3)
sub_ax.set_ylim(-H - t, 2 * t)
plt.show()
Then, we create a new TerminalComponentModeler with an additional port, the modified Simulation, and the modified radiation monitor.
diff_center = [-fx, 0, port_location]
diff_port = coax_port.updated_copy(center=diff_center, name="diff_port")
modeler_diff_feed = modeler.updated_copy(simulation=sim,ports=[coax_port, diff_port], radiation_monitors=[mon_rad_spatial])
# Run the TerminalComponentModeler and populate the scattering matrix of this single CoaxialLumpedPort network.
s_matrix = modeler_diff_feed.run()
Output()
15:56:23 EST Started working on Batch containing 2 tasks.
15:56:25 EST Maximum FlexCredit cost: 0.669 for the whole batch.
Use 'Batch.real_cost()' to get the billed FlexCredit cost after the Batch has completed.
Output()
15:57:08 EST Batch complete.
Output()
Comparison of the radiation patterns for the different feed configurations¶
We use the simulation results to partially reproduce Fig. 7 (b) from [1]. We retrieve the directivities using the helper method get_antenna_metrics_data, which returns an AntennaMetricsData object. We retrieve the partial directivity, which corresponds with the right-handed circular polarization (RHCP) component.
# Get the directivity from the original modeler using the proposed feed
D_right = antenna_parameters_spatial.partial_directivity(pol_basis="circular").Dright.sel(f=freq0)
# Select fields along theta for phi=0 and phi = pi/2
D_Phi_0 = D_right.sel(phi=0).squeeze().values
D_Phi_90 = D_right.sel(phi=np.pi / 2).squeeze().values
# Create a differential excitation by setting the amplitudes of the two ports to be equal in magnitude but opposite in phase.
port_amplitudes = {"coax_port": 1.0, "diff_port": -1.0}
antenna_parameters_shell = modeler_diff_feed.get_antenna_metrics_data(port_amplitudes, monitor_name="rad_spatial")
D_right_diff = antenna_parameters_shell.partial_directivity(pol_basis="circular").Dright.sel(f=freq0)
#These helper functions are used to extract the fields along theta for phi=0 and phi=pi/2, so that theta is in the range [0, 2*pi).
D_Phi_0_diff = antenna_parameters_shell.get_phi_slice(D_right_diff, 0.0)
D_Phi_90_diff = antenna_parameters_shell.get_phi_slice(D_right_diff, np.pi/2)
theta_plot = D_Phi_90_diff.theta.values
# Convert to numpy arrays for plotting
D_Phi_0_diff = D_Phi_0_diff.squeeze().values
D_Phi_90_diff = D_Phi_90_diff.squeeze().values
# Plot the partial directivities similar to [1].
fig, ax = plt.subplots(1, 2, subplot_kw={"projection": "polar"}, figsize=(8, 4))
sub_ax = ax[0]
sub_ax.set_theta_direction(-1)
sub_ax.set_theta_offset(np.pi / 2.0)
sub_ax.plot(theta_plot, 10 * np.log10(D_Phi_0_diff), "-.b", label="Differential feed")
sub_ax.plot(theta_proj, 10 * np.log10(D_Phi_0), "-r", label="Proposed feed [1]")
sub_ax.set_rlim(-20, 12)
sub_ax.set_rticks([-20, -10, 0, 10])
sub_ax.set_title(r"$D_{\rm RHCP}$($\phi = 0$)")
sub_ax.legend(loc="lower center", ncols=2)
sub_ax = ax[1]
sub_ax.set_theta_direction(-1)
sub_ax.set_theta_offset(np.pi / 2.0)
sub_ax.plot(theta_plot, 10 * np.log10(D_Phi_90_diff), "-.b", label="Differential feed")
sub_ax.plot(theta_proj, 10 * np.log10(D_Phi_90), "-r", label="Proposed feed [1]")
sub_ax.set_rlim(-20, 12)
sub_ax.set_rticks([-20, -10, 0, 10])
sub_ax.set_title(r"$D_{\rm RHCP}$($\phi = \pi/2$)")
sub_ax.legend(loc="lower center", ncols=2)
fig.tight_layout()
plt.show()
Gain comparison for the different feed configurations¶
Next, we plot the gain of both feed types. Again, these results can be retrieved from the AntennaMetricsData object by specifying a "circular" polarization basis. The resulting plot will replicate Fig. 6 (b) from [1].
freq = antenna_parameters_shell.f.squeeze() / 1e9
gain_diff = antenna_parameters_shell.partial_gain(pol_basis="circular").Gright.sel(theta=0,phi=0).values.squeeze()
gain_diff_dB = 10 * np.log10(gain_diff)
plt.plot(freq, gain_diff_dB, '-.b', label="Differential feed")
plt.plot(freq, gain_dB, '-k', label="Proposed feed [1]")
plt.xlabel('Frequency (GHz)')
plt.ylabel('Gain (dB)')
plt.title('Gain')
plt.xlim(2.1, 3.1)
plt.ylim(7, 11)
plt.yticks([7, 8, 9, 10, 11])
plt.legend(loc="lower center", ncols=2)
plt.grid(True)
plt.show()
References¶
[1] J. Wu, Y. Yin, Z. Wang and R. Lian, "Broadband Circularly Polarized Patch Antenna With Parasitic Strips," in IEEE Antennas and Wireless Propagation Letters, vol. 14, pp. 559-562, 2015.
[2] C. A. Balanis, Antenna Theory: Analysis and Design. John Wiley & Sons, 2016.
TERMS & CONDITIONS
How the process works:
Try this real URL to see an example:
